DIN 1816 Round Nut with Set Pin Holes

Price And Quantity

Product Description

DIN 1816 Round Nut with Set Pin Holes

DIN 1816 Round Nut with Set Pin Holes Inside

Home
Standards
DIN 1816

Equivalent Standards
CSN 21441
PN 82466
DIN 1816

Dimensions for DIN 1816 Round Nut with Set Pin Holes Inside

d	dk	d1	d4	k	t	h	holes	Weight (7.85kg/dm3)
4H	h11		H11	h14				kg/100pcs
M6x0.75	16	12	2.5	5	4	0.5	4	0.595
M8x1	20	16	2.5	5	4.5	0.5	4	0.95
M10x1	25	20	3	6	4.5	0.5	4	1.81
M12x1.5	28	23	3	6	5	0.5	4	2.23
M14x1.5	30	25	4	7	5	0.5	4	2.88
M16x1.5	32	27	4	7	6	0.5	4	3.12
M18x1.5	34	28	4	8	6	0.5	4	3.92
M20x1.5	36	30	4	8	6	0.5	4	4.25
M22x1.5	40	34	4	9	6	0.5	4	6.05
M24x1.5	42	36	4	9	6	0.5	4	6.45
M24x1.5	45	38	5	10	6	0.5	4	8.1
M28x1.5	50	43	5	10	7	0.5	4	10.3
M28x1.5	50	43	5	10	7	0.5	4	9.55
M30x1.5	52	45	5	11	7	0.5	4	11.1
M32x1.5	55	48	5	11	7	0.5	4	12
M35x1.5	58	50	5	11	8	0.5	4	12.7
M38x1.5	62	54	6	12	8	0.5	4	16.2
M40x1.5	62	54	6	12	8	0.5	4	15
M42x1.5	68	60	6	12	8	0.5	4	18.5
M45x1.5	75	67	6	13	10	0.5	6	25.6
M48x1.5	75	67	6	13	10	0.5	6	24.1
M20x1.5	80	70	6	13	10	0.5	6	28.6
M52x1.5	80	70	6	13	10	0.5	6	26.1
M58x1.5	90	80	6	13	10	0.5	6	37
M60x1.5	90	80	6	13	10	0.5	6	35.1
M62x1.5	95	85	8	14	12	0.5	6	42.3
M65x1.5	95	85	8	14	12	0.5	6	39.2
M68x1.5	100	90	8	14	12	0.5	6	44
M70x1.5	100	90	8	14	12	0.5	6	41.5
M72x1.5	110	100	8	14	12	0.5	6	57.4
M75x1.5	110	100	8	14	12	0.5	6	53.6
M80x2	115	105	8	16	12	1	6	57.5
M85x2	120	110	8	16	12	1	6	68
M90x2	130	120	8	16	12	1	6	84.3
M95x2	135	120	8	16	12	1	6	87.5
M100x2	145	130	8	16	12	1	6	106
M105x2	155	140	8	16	12	1	6	125
M110x2	155	140	8	16	12	1	6	114
M115x2	165	150	10	18	15	1	6	149
M120x2	165	150	10	18	15	1	6	136
M125x2	180	165	10	18	15	1	8	178
M130x3	180	165	10	18	15	1	8	167
M140x3	195	180	10	18	15	1	8	200
M150x3	205	190	10	18	15	1	8	212
M160x3	220	205	10	20	15	1	8	277
M170x3	230	210	10	20	15	1	8	291
M180x3	245	225	10	20	15	1	8	336
M190x3	260	240	10	20	18	1	8	381
M200x3	270	250	10	20	18	1	8	442
